Buttress Thread Gauge in Pune/ Buttress Thread Gauge Manufacturers, Suppliers in Pune

We understand that accuracy and reliability are essential when measuring NPT threads and that is why we take great pride in providing our customers with the best buttress Gauges on the market. Our gauges are designed to provide accurate and reliable measurements every time. We use high-grade materials and advanced manufacturing processes to ensure that our gauges are of the highest quality and meet all industry standards.

Specifications:

Product Name	Buttress Thread Gauge
Brand	Universal-Gauges Pvt. Ltd.
Gauge Type	NO – GO
Handle Design	Single Ended
Material Type	Steel
Usage	Industrial

What is Buttress Thread Gauge?

Buttress thread form, also known as buttress thread form or plug thread form. Is an asymmetrical thread profile with square and beveled sides? These are commonly used on lead screws where the load is primarily unidirectional.

Properties

• The buttress thread form is designed primarily to handle axial thrust applied in one direction. The load-bearing thread face is perpendicular or slightly inclined (typically 7° or less) to the thread axis.
• The resulting thread form has the same low-friction properties as the square thread form, but with approximately twice the shear strength due to the longer thread base.
• This thread form is also relatively easy to machine on a thread milling machine, as opposed to the difficult square thread form.

Parts of Buttress Thread Gauge:

• Gauges for buttress threads: Recommended gauges and measurement methods for male and female threads are defined in the ASME B1.9 standard.
• Allowance: Tolerance (play) is required on all male threads to facilitate assembly of the parts.
• Large diameter: The maximum thread diameter is the diameter of the male thread crest or female thread root.
• Small diameter: Minimum thread diameter. The root diameter of an external thread or the crest diameter of an internal thread.
• Thread root: There are two choices for thread roots. These are rounded, flat roots.
• Rounded root: At the root of the male and female threads, equal radii are formed tangential to the load and relief flanks.

Acme screws are commonly used as split nuts, bushings, vises, and lead screws in mechanical devices. These threads are also required in applications requiring high torque and power transmission such as lathes, milling machines, presses, and CNC systems.

It is commonly used in the oil and gas industry where strength and durability are important to ensure the safety of people and equipment. In such applications Acme threads are used in valve stems, hydraulic couplings, and related fasteners for heavy-duty applications.
